Prestige R1 DTF Printer + Phoenix Air 16x20 Oven Bundle
Prestige R1 DTF Printer + Phoenix Air 16x20 Oven Bundle
The Prestige R1 DTF Printer + Phoenix Air 16x20 Oven Bundle is an affordable 13" starter DTF system for beginners who want the R1 printer with oven curing, without stepping into a full shaker dryer workflow yet.
This package combines the Prestige R1 DTF printer, Phoenix Air 16x20 curing oven, DigiRIP RIP software, DTF film, Color Prime ink, hot melt powder, cleaning supplies, free virtual installation support, and one free seat in our DTF Like a Pro class.
Which DTF package should you get? If your goal is to produce approximately 64 to 86 shirts per day and you want a lower-cost R1 setup with oven curing, this package is a strong step up from printer only.
- 13" maximum print width
- Ideal for approximately 64 to 86 shirts per day
- Includes Phoenix Air 16x20 curing oven
- Manual powdering + oven curing workflow
- Includes DigiRIP RIP software
- Includes starter DTF film, ink, powder, and cleaning supplies
- Includes free virtual installation support
- Optional on-site installation available for $2,750.00
- Includes one free seat in our DTF Like a Pro operation class
- White Ink Management System
- Passive and active auto-cleaning features
- Drop ship item
Important: This is a drop ship item and does not ship from the KOLORMATRIX warehouse. Contact us before ordering if you have questions about current lead time, freight, installation support, setup requirements, supplies, or whether this is the right R1 package for your shop.
Installation Support
This Prestige R1 DTF Printer + Phoenix Air 16x20 Oven Bundle includes free virtual installation support to help guide you through setup and installation.
For customers who prefer hands-on assistance, optional on-site installation is available for $2,750.00.
- Free virtual installation support included
- Optional on-site installation available for $2,750.00
- Installation scheduling subject to availability
- Site readiness requirements may apply
- Travel, access, electrical, ventilation, workspace, and equipment placement requirements may apply
Important: The customer is responsible for having the proper workspace, power requirements, ventilation, computer, internet access, and equipment placement ready before installation.
Bundle Includes
- Prestige R1 DTF Printer
- Phoenix Air 16x20 Curing Oven
- DigiRIP RIP Software
- Color Prime DTF Film A3+ 13" x 109 yard roll
- Color Prime DTF Ink CMYK + White — 1kg total
- Color Prime DTF Hot Melt Powder — 1kg
- Color Prime DTF Cleaning Solution — 1kg
- Isopropyl Alcohol — 16oz
- Lintless Wipes — 4" x 4", 30 pack
- DTF Station 7" Cleaning Swabs — 50 pack
- Color Prime DTF Blanks Sample Kit
- Free virtual installation support
- One free seat in KOLORMATRIX’s DTF Like a Pro class
The Prestige R1 is available in multiple package levels depending on how you want to build your DTF workflow.
| Package | Best For | Includes |
|---|---|---|
| R1 Printer Only | Shops building their own DTF workflow | Prestige R1 printer |
| R1 Printer + Oven | Starter users who want manual powdering and oven curing | Printer + Phoenix Air 16x20 curing oven |
| R1 Printer + Shaker Dryer | Users who want a more complete automated DTF workflow | Printer + Miro 13 Max shaker dryer |
| R1 Printer + Shaker Dryer + Oven | Users who want the most complete R1 setup | Printer + shaker dryer + curing oven |
This page is for the R1 Printer + Oven Bundle. If you are unsure which package is right for you, contact KOLORMATRIX and we’ll help you choose the best setup for your space, budget, and production goals.
Why Buy From KOLORMATRIX?
Buying a DTF printer is not just about the machine. DTF success depends on proper workflow, supplies, maintenance habits, installation support, training, and real-world guidance.
While this Prestige R1 bundle is a drop ship item, KOLORMATRIX has a working DTF showroom where customers can see larger production DTF systems in person, including our Prestige XL3 shop package and R2 Pro shop package.
That means you are buying from a team that understands DTF printing, screen printing, transfers, supplies, and production equipment — not just a catalog listing.
- Real-world DTF and screen printing experience
- DTF showroom with production systems on display
- Free virtual installation support included
- Optional on-site installation available
- One free seat in our DTF Like a Pro class included
- Help choosing between R1 package options
- Support understanding printer size, workflow, supplies, and maintenance
- Access to DTF inks, films, powders, cleaning supplies, ovens, shaker dryers, and heat presses
- Atlanta-based support from an experienced print supply team
Who This Package Is Best For
The Prestige R1 Printer + Oven Bundle is ideal for users who want the R1 printer with oven curing, while keeping the overall package more affordable than a shaker dryer setup.
This package is a strong fit for:
- Entry-level DTF printing users
- Beginners who want printer + oven curing
- Small apparel businesses
- Home-based or garage-based print shops
- Shops upgrading from vinyl, sublimation, or outsourcing transfers
- Small clothing brands bringing DTF transfers in-house
- Creators who want to print larger designs than A4 format
- Low-to-mid volume custom apparel production
- Shops not ready for a shaker dryer yet
If your goal is automated powdering and curing, consider the R1 Printer + Miro 13 Max Shaker Dryer Bundle. If you want the most complete R1 setup, consider the R1 Printer + Shaker Dryer + Oven package.
Printer + Oven Workflow
This package uses a manual powdering and oven curing workflow.
With DTF printing, the general process includes printing the transfer, applying hot melt powder, curing the powder, and pressing the finished transfer onto the garment. With this package, the Phoenix Air 16x20 oven is used for curing after powder is applied.
This is a strong option for beginners who want a more affordable R1 starter package before moving into a shaker dryer workflow.
- Print with the Prestige R1 DTF printer
- Apply hot melt powder manually
- Cure using the Phoenix Air 16x20 oven
- Heat press transfers onto garments
- Great for learning the DTF process before investing in automation
Free DTF Like a Pro Class Seat
Purchase this Prestige R1 DTF Printer + Phoenix Air 16x20 Oven Bundle from KOLORMATRIX and receive one free seat in our DTF Like a Pro class.
This class is focused on DTF operation, workflow, maintenance, troubleshooting, and production best practices. It is not an installation service.
DTF equipment requires more than just setup. Proper operation training can help reduce wasted supplies, clogged printheads, downtime, failed transfers, and frustration as you learn the process.
- One free DTF Like a Pro class seat included with purchase
- Focused on operation, workflow, maintenance, and production
- Learn printing, powdering, curing, pressing, and troubleshooting basics
- Great for first-time DTF printer owners
- Class scheduling subject to availability
Free class seat applies to the original purchaser. Travel, lodging, installation, and additional attendees are not included unless otherwise arranged with KOLORMATRIX.
Printer Features
- Epson F1080 printhead
- White Ink Management System: timed white ink stirring system to circulate and maintain white ink inside the printer
- Passive auto-cleaning: when the printer is left on, it automatically maintains and cleans the printhead every 4 hours
- Active auto-cleaning: during set intervals, even during printing, the printer can stop to clean the printhead
- Head strike sensor: helps prevent damage to the printhead
- Auto ink alert system: informs the user when ink is running low
- Automatic film sensor: stops printing if film runs out or is not detected
- 13" maximum print width
- Up to 13.45 sq. ft. per hour print speed
Technical Specs
- Printer: Prestige R1 DTF Printer
- Print Head: Epson F1080
- Mainboard: Hosonsoft
- Interface: TCP
- Software: DigiRIP RIP Software
- Software Compatibility: Windows PC only; no tablets, Surface, etc.
- Maximum Film Width: 13.78" / 35 cm
- Maximum Print Width: 13" / 33 cm
- Printing Speed: 13.45 sq. ft. per hour / 1.25 sq. m per hour at 700 x 1080 DPI
- Machine Weight: 82 lb / 37 kg
- Product Dimensions: 32.3" W x 25.2" D x 12.6" H
- Estimated Daily Output: 64–86 pieces based on 12" x 14" design size and 8-hour day
- Suitable User Level: Entry-level DTF printing users
Note: Packaging dimensions, packaging weight, and oven specifications may vary. Contact KOLORMATRIX before ordering if you need exact freight or setup details.
Warranty
This bundle includes manufacturer warranty coverage based on current terms and approved use of the equipment.
- Conditional warranty on printhead
- Limited 1-year warranty on non-consumable parts
- Use of non-approved ink, film, powder, or supplies may void warranty coverage
- Warranty terms may vary by manufacturer policy and selected support options
Please review all current manufacturer warranty terms before purchase. Contact KOLORMATRIX if you have questions about warranty coverage, setup, supply compatibility, or maintenance requirements.
Compatible Applications
DTF transfers can be applied to many common apparel and accessory items, making the Prestige R1 a flexible system for custom decoration.
- T-shirts
- Garments
- Tote bags
- Caps
- Cotton fabrics
- Polyester fabrics
- PU materials
- Additional compatible fabrics and products
Always test your garment, fabric, powder, ink, film, and heat press settings before running production orders.
DTF Showroom & Upgrade Path
KOLORMATRIX has a DTF showroom featuring larger production DTF systems, including the Prestige XL3 shop package and R2 Pro shop package.
If you are unsure whether the Prestige R1 + Oven Bundle is the right fit, contact us before purchasing. We can help you compare this 13" DTF bundle against smaller starter setups and larger production systems based on your expected order volume, gang sheet size, production goals, workspace, and budget.
Common upgrade paths include:
- Prestige A4 starter DTF setup
- Prestige R1 13" DTF printer only
- Prestige R1 printer plus oven
- Prestige R1 printer plus shaker dryer
- Prestige R1 printer plus shaker dryer and oven
- Prestige XL3 shop package
- R2 Pro shop package
Drop Ship Information
This product is a drop ship item. It does not ship from the KOLORMATRIX warehouse.
- Usually ships in approximately 2 to 3 business days
- Ships directly from supplier or manufacturer network
- Lead times may vary
- Freight or delivery coordination may be required
- Contact us before ordering for current availability
- Delivery address and access requirements may affect shipping options
Because DTF equipment requires setup, maintenance, and proper supplies, we recommend contacting KOLORMATRIX before purchase if this is your first DTF printer.
Important Setup Notes
- DTF printers require regular use and maintenance
- White ink must be properly circulated and maintained
- Proper humidity, temperature, and clean workspace conditions matter
- DigiRIP software requires a compatible Windows PC
- DTF printing requires testing for time, temperature, pressure, powder, and film compatibility
- Supplies such as ink, film, powder, cleaning solution, swabs, and wipes should be kept on hand
- Training is strongly recommended for first-time DTF users
- Manual powdering requires good technique, cleanliness, and safe handling practices
This is production equipment, not a plug-and-forget desktop printer. Proper setup, maintenance, and operator training are important for success with DTF printing.
FAQ
Which R1 package is this?
This page is for the Prestige R1 DTF Printer + Phoenix Air 16x20 Oven Bundle.
Does this package include a shaker dryer?
No. This package includes the Prestige R1 printer and Phoenix Air 16x20 curing oven. If you want automated powdering and curing, choose the R1 printer + shaker dryer package.
How many shirts per day is this package good for?
The Prestige R1 package is a good fit for approximately 64 to 86 shirts per day, based on a 12" x 14" design size and an 8-hour workday. Actual output may vary based on artwork size, print settings, curing workflow, operator experience, and production setup.
Does this include installation?
Yes. This bundle includes free virtual installation support. Optional on-site installation is available for $2,750.00, subject to scheduling and site readiness.
Does this include training?
Yes. This bundle includes one free seat in our DTF Like a Pro class. The class focuses on operation, workflow, maintenance, troubleshooting, and production best practices. It is not an installation service.
Is this item in stock at KOLORMATRIX?
No. This is a drop ship item and does not ship from the KOLORMATRIX warehouse.
Can I see DTF equipment in person at KOLORMATRIX?
Yes. KOLORMATRIX has a DTF showroom with larger DTF systems, including the Prestige XL3 shop package and R2 Pro shop package.
What is the max print width?
The Prestige R1 has a maximum print width of 13".
Does this include software?
Yes. DigiRIP RIP software is included. A compatible Windows PC is required.
What supplies are included?
This bundle includes DTF film, CMYK + white ink, hot melt powder, cleaning solution, isopropyl alcohol, lintless wipes, cleaning swabs, and a DTF blanks sample kit.
Should I buy this or the R1 printer + shaker dryer package?
Choose this package if you want a lower-cost R1 starter setup with oven curing and are comfortable manually powdering transfers. Choose the R1 printer + shaker dryer package if you want a more automated powdering and curing workflow.
