Home » ICC 7600 Flex Cure Plastisol Ink
International Coatings

ICC 7600 Flex Cure Plastisol Ink

In stock
SKU: ICC7602
$38.03
Sale $43.00 $38.03
7600 Color
Ink Size

Info

  • 26 vibrant ready-for-use colors
  • Formulated for superior performance with high-speed wet-on-wet automatic printing as well as manual printing
  • Suited for fine detail and halftone printing using finer mesh counts
  • Easy to print, creamy and great body
  • No build-up and less squeegee pressure
  • Flex Cure 275F to 325F
  • Mesh count 60 to 305
  • Fabrics: 100% cotton, 50/50 cotton poly blends

Download ICC 7600 Color Card

Download TDS: Technical Data Sheet

GENERAL PURPOSE COLORS (7600 SERIES)

International Coatings’ General Purpose Color (7600 Series), High Pigment (HP) and Pro-Brite™ (PB) 4-Color Process inks are now part of our expanded line of FlexCure™ screen printing inks. FlexCure™ inks offer a ‘flexible’ curing range - from a low 275°F/135°C to the standard 325°F/163°C.

General Purpose Colors (7600 Series) are vibrant, ready-for-use and popular colors. It offers superior performance through fast production speeds, good opacity, and a wide range of popular colors. General Purpose Colors can cure as low as 275ºF (135ºC).

  • 26 vibrant ready-for-use colors
  • Formulated for superior performance with high-speed wet-on-wet automatic printing as well as manual printing
  • Suited for fine detail and halftone printing using finer mesh counts
  • Easy to print, creamy and great body
  • No build-up and less squeegee pressure

SPOT FLASHING

The 7600 Series inks will spot dry, with a very low after flash tack. Dwell time is dependent on the spot dryer used. In some cases, you may have to lower the heat of the spot cure unit because too much heat may actually make the ink tacky. When you spot dry, you are only partially fusing or gelling the surface of the ink. The ink should be just dry to the touch, with no lift-off, but not totally fused. Total fusing of any flashed color may cause inter-coat adhesion problems with the inks printed on top of the flashed ink. Final fusing or curing should occur in the dryer.

IMPORTANT INFORMATION

Use an underbase print when printing General Purpose Color inks onto dark fabrics. Use 7014, 7022, 7038, or 7041 white as an underbase ink. To achieve a softer hand and faster production speeds, print underbase ink through finer mesh counts (230 to 305 t/in or 90 to 120 t/cm mesh).

Adding too much reducer or other additives to the 7600 Series inks may cause curing/ fusing or dye migration problems. Excessive squeegee pressure will drive the 7600 Series inks through the fabric being printed. Adjust squeegee pressure, angle and off-contact to insure proper shear and lay down of the printed ink.

Test dryer temperatures and wash-test printed product before and during a production run.

RECOMMENDED FABRICS 100% Cotton 50/50 Cotton/Polyester Blends INK

APPLICATION 7600 Series Colors should be printed without any modifications ADDITIVES If modification is necessary, use 1% to 3% by weight of 1110 Curable Reducer for the standard inks

SCREEN MESH 60-305 monofilament

EMULSION Any direct or indirect emulsion  or capillary film in the 35 to 70  micron range, depending on the opacity desired

SQUEEGEE 65-70 Durometer Sharp edge

CURE TEMPERATURES 275F to 325°F (163°C) entire ink film

CLEAN-UP Any eco-friendly plastisol screen wash

STORAGE OF INK CONTAINERS 65º to 90ºF (18ºC to 32ºC) Avoid storage in direct sunlight Keep containers well sealed
